ALL TERRAIN CRANES

KA-3000RX ALLTERR

KA-1300RX
Traveling position in working site

GENERAL SPECIFICATIONS

General Dimensions(L x W x H)
17,740 x 2,990 x 4,100mm
Gross Vehicle Weight
43,940kg
Maximum Lifting Capacity
300t x 2.5m
Boom length / sections
14.4 - 55.0m
5 sections
SL Jib Length / sections / offset angles
10.85 - 35.0m
4 sections
0° - 60°
HL Jib Length / sections / offset angles
13.0m, 22.0m, 31m, 40m, 47m, 54m
6 sections
10° - 60°
Outrigger width
5,400 - 9,400mm
