CR-130Rf

CR-130Rf

General Specifications

  • General Dimensions
    (L x W x H)

    7,465 x 1,995 x 2,870mm
  • Gross Vehicle Weight
    13,745kg
  • Maximum Lifting Capacity
    13t x 1.7m
  • Boom length / sections
    5.3 - 24.0m
    6 sections
  • Searcher Hook length /
    offset angles

    0.8m
    2 positions (high / low)
  • Jib length / sections / offset angles
    3.6 - 5.5m
    2 sections
    5° - 60°
  • Outrigger width
    1,640 - 4,750mm
